| Model Number |
WPF3-YZ |
WPF3.9-YZ |
|
| Lift Rated Capacity |
kg |
300 |
300 |
| Maximum working height |
mm |
5000 |
5900 |
| Maximum platform height |
mm |
3000 |
3900 |
| Overall Length (With ladder I Without ladder) |
mm |
1340/1250 |
1340/1250 |
| Overall Width |
mm |
760 |
760 |
| Overall Height |
mm |
1830 |
1830 |
| Platform size |
mm |
1170 x 600 |
1170 x 600 |
| Ground clearance |
mm |
60 |
60 |
| Wheel base |
mm |
1010 |
1010 |
| Minimum turn radius |
mm |
1400 |
1400 |
| Driving Motor |
V/kw |
2x24/0.4 |
2x24/0.4 |
| Lifting Motor |
V/kw |
24/1.2 |
24/1.2 |
| Running speed ( platform Stowed ) |
km/h |
4 |
4 |
| Running speed ( platform Elevated ) |
km/h |
0.8 |
0.8 |
| Rising/falling speed |
sec |
20/30 |
20/30 |
| Battery |
V/Ah |
2x12/60 |
2x12/60 |
| Charger |
V/A |
24/10 |
24/10 |
| Maximum climbing ability |
% |
10-15 |
10-15 |
| Maximum working allowable angle |
/ |
2° |
2° |
| Driving Wheel |
mm |
Φ230 x 80 |
Φ230 x 80 |
| Front wheel |
mm |
Φ230 x 80 |
Φ230 x 80 |
| Overall Net Weight |
kg |
650 |
650 |
The factory reserves the amending right for the materials And technical specifications
